Being a leading company in industrial powder processing, engineering stone crushing and construction sand making, Vipeak Heavy Industry Machinery Group Company is a high-tech mining machinery company in China. Our service has expanded to the entire world, almost including 75 countries. From engineering stone, construction sand to engineering powder. All equipments from VIPEAK exert great productivity and stability on working sites, make the customers satisfied. We strongly feel that customers do not only need equipments with good performance, but in the hope of their efficiency, their benefit and their competitive power. So high value added equipments have been produced. We have never been satisfied; our customer's satisfaction is our utmost objective. Vipeak Declaration is made of Vipeak Spirit, Vipeak Aim, Vipeak Concept, Vipeak Brand Concept and Vipeak Service Concept.
Vipeak: Technology is source, perseverance makes success
Vipeak Aim: Eligible quality is the obligation for society, and good quality is the contribution for society
Vipeak Concept: To be your satisfied partner(all the customers and partners of our company and the staff in our company are satisfied).
Vipeak Spirit: Efficiency, Communication, Service, Study
Jaw Crusher
Model： PE Series, PEX Series
Keywords: crusher, jaw crusher, stone crusher
Jaw Crusher is one of the most popular stone-crushing equipments in the world, Jaw Crusher is ideally suitable for primary and secondary crushing. The highest anti-pressure strength of crushed material is 320MPa. It is widely used in mining, metallurgy, construction, highway, railroad, and chemistry industries and etc. Many models are available according to your different fineness requirements.
Main structure of Jaw Crusher:
Jaw Crusher mainly consists of main frame, eccentric shaft, belt wheel, flying wheel, movable jaw plate, side board, toggle plate, back seat for toggle plate; gap adjusting screw, returning spring, fixed jaw plate, movable jaw plate and so on. The toggle plate also plays the role of protecting.
Working Principle of Jaw Crusher:
Motor drives belt and belt pulley, makes moving jaw up and down through eccentric shaft. When the moving jaw is up, the angle between lining plate and moving jaw becomes large, and this will push moving jaw plate close to the fixed jaw plate. During this process, the material is crushed and ground, thus the crushing will be done. When the moving jaw is down, the angle between lining plate and moving jaw becomes small, the moving jaw plate will leave the fixed jaw plate on account of the effect of pulling bar and spring, and then the crushed material will be discharged from the lower opening of the crushing room. With the motor continuously rotating and the material periodically crushed and discharged by the crusher, the mass production can be realized.
http://www.crushingmill.com
http://www.crushingmill.com/Jaw.html
http://www.vipeakgroup.com/index.asp
http://www.vipeakgroup.com/Jaw.html
http://www.grinderpro.com
http://www.grinderpro.com/Jaw.html
http://www.grinderpro.com/Spanish/Jaw.html
http://www.vipeakgrinder.com/
http://www.vipeakgrinder.com/jaw_crusher.html
And also we have many models of Jaw Crusher: such as PE Series and PEX Series
Model: PE150?250,PE150?750,PE250?400,PE500?750,PE600?900,PE750?1060,PE900?1200,PEX250?750,PEX250?1000,PEX250?1200,PEX300?1300
Max Feeding Size (mm):125, 210, 340, 425, 500, 630, 750, 850, 1020
Capacity (t): 5~16, 5~20,16~65,45~100,90~180,110~260,160~410,250~480, 350~800
Impact Crusher
PF Series
Keywords: crusher, impact crusher, stone crusher, crushing machine
Impact Crusher is used in both primary and secondary crushing applications of aggregate, and in recycle crushing of reinforced concrete, asphalt and other construction and debris. VIPEAK is a reliable supplier of Impact Crusher with new design.
Impact Crusher is composed of rotor, impact rack, frame, ratchet cover device, Transmission Device and other parts.
Working Principle of Impact Crusher:
When the Impact Crusher works, the motor drives the rotor rotate of the Impact Crusher with high speed, on the rotor where installed the hammers. When the materials get into the area which the hammers affect, under the impact function of the hammer at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers effects for being re-crushed. The materials from large to small all to be crushed at the impact chamber repeatedly. The process won?t stop till the material are crushed to the required size and then discharged from outlet of the Impact Crusher.
Characteristics of Impact Crusher:
Excellent cubic final products
Special structure
Non-key connection
High chrome hammer
Durability in long time simplicity in operation
Easy adjustment, high reduction ration
Good performance and high reliability
http://www.grinderpro.com
http://www.grinderpro.com/Impact.html
http://www.grinderpro.com/Spanish/Impact.html
http://www.vipeakgroup.com/index.asp
http://www.vipeakgroup.com/Impact.html
http://www.crushingmill.com
http://www.crushingmill.com/Impact.html
http://www.vipeakgrinder.com/
http://www.vipeakgrinder.com/impact_crusher.html
Model: PF-1007, PF-1010,PF-1210,PF-1214,PF-1315
Max Feeding Size (mm):300, 350,400
Capacity (t): 35-50, 50-80, 70-120, 80-180, 120-260
Symons Cone Crusher:
Model: various series
Keywords: cone crusher, crusher, stone crusher, rock crusher
Detailed Product Description
For higher productivity, better reliability and flexibility, long service life, and better final product quality, the Symons type cone crusher is absolutely your best choice.
Symons type cone crusher offer several outstanding features such as excellent tramp release system, unique hydraulic lifting system, high crusher throw and reasonable cavity design, all of these features ensure the Symons type cone crusher can offer the unbeatable performance in secondary, tertiary and quaternary applications.
If your aggregate or mining business demands the 24-hours running, high-reduction, big capacity application, you will find the Symons type cone crusher optimized for your demands.
The innovations like the stable lubrication, excellent sealing feature, great abrasive material applied in key components and rugged construction effectively reduce the wear rate , extend the replacement period of the spare parts, evidently reduce the production cost in per ton hour material processed. All of these can help you to achieve the highest level of profitability.
Symons Type Cone Crusher Main Features:
1. Higher capacity and less wear costs.
2. Wide range of application suitability.
3. Easy to maintain, reduce the downtime and maintenance costs.
4. Stable running performance and easy operation.
http://www.vipeakgroup.com/
http://www.vipeakgroup.com/Symons.html
http://www.crushingmill.com
http://www.crushingmill.com/Spring_Cone_Crusher.html
http://www.grinderpro.com/index.asp
http://www.grinderpro.com/Symons.html
http://www.grinderpro.com/Spanish/Spring.html
http://www.vipeakgrinder.com/
http://www.vipeakgrinder.com/spring_cone_crusher.html
Sand Making Machine:
Model：PCL Series
Keywords: sand making machine, crusher, stone crusher,VSI crusher, PCL crusher
Sand Making Machine (namely PCL Vertical Shaft Impact Crusher) is of high-power and low-consumption, which is designed depending on several year?s hard work and study of mechanical mining equipment. Sand Making Machine absorbed the advanced technology of the same products of Barmac Company of America, now is of the international level. Sand Making Machine plays an important role in crushing minerals into pieces. PCL Vertical shaft Impact Crusher is widely used in all kinds of mineral, cement, corhart, carborundum grain, glass raw material, machine making construction sand, stone stock and all kinds of metallurgy slag, especially carborundum, sintered bauxite, magnesite, and so on materials with features of very hard and anticorrosion. And Sand Making Machine is more productive than other kind of crushers.
Characteristics of Vertical Shaft Impact Crusher (Sand Making Machine):
Simple structure and low operating cost;
High crushing ratio with low consumption;
Function of fine crushing and crude grinding
Slightly influenced by moisture content of material, and the max moisture content is about 8%;
More suitable for crushing mid-hardness and high hardness materials;
Cubic shape of final products, high density of piling up and low iron pollution;
More wearable and easier maintenance;
Low working noise (lower than 75 decibel) and light dust pollution.
http://www.crushingmill.com
http://www.crushingmill.com/Sand_Making_Machine.html
http://www.vipeakgroup.com/index.asp
http://www.vipeakgroup.com/Sand_Making.html
http://www.grinderpro.com
http://www.grinderpro.com/Sand_Making.html
http://www.grinderpro.com/Spanish/Sand_Making.html
http://www.vipeakgrinder.com/
http://www.vipeakgrinder.com/sand_making_machine.html
Model: PCL Series
Impeller Speed(r/min):800-1200, 1000-1700, 1500-2500, 2000-2600
Capacity (t/h):8-50, 25-65, 60-150, 100-260, 160-360
High Pressure Medium Speed Grinder
Keywords: grinding mill. grinder machine, powder grinder, roller mill
Model：YGM Series
High Pressure Medium Speed Grinder (High Pressure Suspension Mill), the new design, from VIPEAK is used to grind barite, limestone, kaolin, and ceramics and slag, whose Moh's hardness is below 9.3 scales, non-inflammable and non-explosive material.
Working Principle of High Pressure Medium Speed Grinder:
The grinding Process of the Main Mill is that the transmission device brings along the Central Shaft to drive. The upper part of the shaft connects with the Quincunx Rack, on the frame is loaded with the roller assembly, and forms a swinging pivot. The central shaft does revolve around the central rotation, at the same time it revolves around the grinding rings, and it self also rotates on account of the grinding effect. The shovel system, in the lower part of rollers, is loaded on the lower part of the Quincunx Rack. In the process of rotating of the shovel and the roller, the material will be fed gasket layer between the rollers and ring. The outside centrifugal force (compression force) yielding in this process will process the material into small powder, thus the desired powder is obtained.
Product Advantages of High Pressure Medium Speed Grinder:
(1) Our patent product
(2) Product size is adjustable in the range of 80 - 425 meshes
(3)Better design, low cost
http://www.crushingmill.com
http://www.crushingmill.com/Suspension.html
http://www.grinderpro.com/index.asp
http://www.grinderpro.com/Suspension.html
http://www.grinderpro.com/Spanish/Suspension.html
http://www.vipeakgroup.com/index.asp
http://www.vipeakgroup.com/Suspension.html
http://www.vipeakgrinder.com/
http://www.vipeakgrinder.com/high_pressure_suspension_grinder.html
Name: HGM Series Micro-powder Grinder
Keywords: grinder mill, grinding mill, micro-powder, hgm mill, ultrafine grinder
Model: HGM Series
HGM series of three-rings and medium-speed micro powder grinder is a new type of making micro powder machines through more than twenties times research and improvement, depending on two decades of hard work & experience and inputting the latest mechanical techniques of Sweden. It is an incorporated one of the two countries and a leader of the grinding industry nowadays.
HGM series of three-rings and medium-speed micro powder grinder is widely used in making fine powder or micro powder, and the raw materials should be non-inflammable and non-explosive under the Moh's hardness less than 6 grade such as limestone, calcite, dolomite, kaolin, bentonite, talc, illite, pyrophillite, barite, meerschaum, fluorite, potash ore, etc. The lifetime of spare parts is relied on the hardness of raw materials, and is lowered once the Moh's hardness is up to 4-6 grade.
Main features:
1, High efficiency and lower consumption. In the condition of the same material, power and the fineness, its capacity is increased by 40% compared to the jet mill and mixing grinder.
2, Longevity. In the condition of the same power and the fineness, the spare parts have a longer lifetime, usually more than one year, to the shaft impactor crusher and the turbine crusher.
3, Non-bearings and non-bolt in the grinding chamber. Because of this, these questions destroying the machines can never exist for bearing, sealing element or the bolts loose.
4, The fineness of final products can add up 5μm, and screening rate is 97%.
http://www.crushingmill.com
http://www.crushingmill.com/HGM.html
http://www.grinderpro.com/index.asp
http://www.grinderpro.com/HGM.html
http://www.grinderpro.com/Spanish/HGM.html
http://www.vipeakgroup.com/index.asp
http://www.vipeakgroup.com/HGM.html
http://www.vipeakgrinder.com/
http://www.vipeakgrinder.com/HGM.html
Ball Mill
Keywords: ball mill, cement mill, grinding mill, grinder mill
Ball Mill is an efficient tool for grinding many materials into fine powder. Ball Mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine. To use the Ball Mill, the material to be ground is loaded into the Neoprene barrel that contains grinding media. As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours.
Quite simply, the longer the Ball Mill runs, the finer the powder will be. Ultimate particle size depends entirely on how hard the material you're grinding is, and the time how long the Ball Mill runs. Our Ball Mills have been used to grind glass, powder food products, create custom varnishes, make ceramic glaze, powder various chemicals, and make Black Powder.
Model: MQG Series
The feeding size(mm):≤25
Quantity (t):0.65-2, 1.6-5.8, 4-10, 7.5-17, 10-22, 8-36
If you want to know more about the Ball Mill, Please directly inquiry us!
http://www.crushingmill.com
http://www.crushingmill.com/ball.html
http://www.grinderpro.com/index.asp
http://www.grinderpro.com/ball.html
http://www.grinderpro.com/Spanish/ball.html
http://www.vipeakgroup.com/index.asp
http://www.vipeakgroup.com/ball.html
http://www.vipeakgrinder.com/
http://www.vipeakgrinder.com/ball_mill.html
