Henan Dayu Industry Co., Ltd is a corporation specialized in road marking machine's develop, research, marketing and engineering construction.
Products range is road marking machine, road marking paint and other road auxiliary equipments, including hand-push thermoplastic road marking machine, self-propelled thermoplastic road marking machine, sitting type thermoplastic road marking machine, cold solvent road marking machine, two-component road marking machine,
thermoplastic convex road marking machine, thermoplastic pedestrian road marking machine, hydraulic double(or single)-cylinder pre-heater, road marking remover, wind-force road cleaner and so on.
DY-HPA Hand-Push Airless Road Marking Machine is one of the frequently-used equipment in cold solvent road marking construction. It has refined and simple exterior design, and is easy to operate and can meet different specifications of construction requirements.
Technical Parameters:
1) Engine：The United States Briggs & Stratton 5.5.0HP gasoline engine.
2) Paint pump: Adopt imported diaphragm high pressure airless pump, large flow volume and stable pressure. The highest pressure is 20mpa (work pressure is 10-15mpa), the largest flow volume is 8.5L/min.
3) Paint tank: The capacity is 60L. Equipped with filter device in paint tank and a whole type filter in the feeding port of tank .
4) Spray gun: Double manual spray guns with hard-edged cylindrical nozzle reverse decontamination, to decontaminate at any moment. The 6m lengthening pipe is equipped used for spraying arrow, words and other special marks.
5) Direction control: Back wheel locating device ensures the machine to walk along straight line and easy to operate when turning.
6) Spray width: 100-450mm.
7) Net weight: 190kg.
8) Dimension: 1280 mm(length)?980 mm(widthe)?1030 mm(height)
